3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy

Hebei Pinglei Weighing Apparatus Co., Ltd
Contact Now
    Buy cheap 3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy from wholesalers

    Buy cheap 3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy from wholesalers
    • Buy cheap 3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy from wholesalers

    3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy

    Ask Lasest Price
    Brand Name : Pinglei
    Model Number : SCS
    Certification : ISO9001
    Price : negotiation
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 100 Sets Per Week
    Delivery Time : 10 Days
    • Product Details
    • Company Profile

    3*16m 120 Ton Pit Type Weighbridge OIML Approved Accuracy For Coal Mining Industy

    3*16m 120 Ton Electronic Pit Type Weighbridge Truck Scale Price

    Electronic Road Vehicle Scale


    1. Capacity: 30-200T
    2. Accuracy: International OIML-III
    3. Width: 2~4m; Length: 5~24m;

    4. Build in the shortest time

    Truck scale is widely used in port, storage, loading bags and is convenient in operation and simple in

    maintenance.


    Features:


    1. Accuracy: OIML approved

    2. Rugged and reliable load cell

    3. Operating voltage: 220VAC

    4. Wide: 2~4m

    5. Length: 5~24m

    6. Working temperature:-40/+50 degree (the indicater);-40/+75 degree (the load cell)

    7. Precision: 10Kg, 20Kg, 50Kg, 100Kg

    8. Minimum capacity: 30~200t


    How does a truck scale work?


    When the truck is docked on the platform,under the action of gravity,the weighing platform reports gravity to the sensor,resulting in deformation of the elastomer attached to the sensor,The strain gauges and bridges on the elastomeric strain beam are out of balance and output an electrical signal proportional to the weight value.

    Where is a truck scale application?

    Coal mining industy,chemical industry,agriculture,animal husbandry,cement industry,power plant,port,construction site and others,highway etc.


    How to install and use a truck scale?


    Leave your email address and we will send the video of installation and how to use a truck scale for free.
    And we have more products using video prepare for you.
    ItemCapacity(MT)Platform Size(m)Module/SectionLoad CellGraduation
    SCS-20t202.3×5m1/145 kg
    2.3×8m2/26
    SCS-30t303×5.8m1/2410 kg
    3×9m2/46
    3×11.4m2/46

    SCS-50/

    60t

    50/603×9m2/4610 kg
    3×11.4m2/46
    3×16m3/68
    SCS-80t803×11.4m2/4620 kg
    3×16m3/68
    3.2×16m3/68
    SCS-100t1003×14m2/4650 kg
    3×16m3/68
    3.4×18m3/68
    SCS-120t1203×16m3/6850 kg
    3.2×18m3/68
    3.4×21m4/810
    SCS-150t1503×16m3/6850 kg
    3.2×18m3/68
    3.4×21m4/810
