30 Ton Electronic Pit Type Lorry Weighbridge Digital Truck Scale

Specification of 60 ton weighbridge

1. Truck scale u-shaped steel beams,uneasy deformation, good craftwork

2. Intelligent digital weighing instrument display, long-term working stability,

3. Easy for installation and maintenance.

4. Anti-jamming, anti-vibration, anti-corrosion,anti-wear capacity etc.
5. With high-precision sensors, testing accuractly, low failure rate

6. Use anti-surge junction box to protect weighing signal box,

7. Show tare, gross/net weight, date,time by digit.Auto tare,re-zero function.

8. Print all kinds of weighing lists

9. Dynamic check, digit filter and auto zero track
10. Interface:RS232/standard communication interface
11. Standard indicator: A9+

Technical Parameter:

1. Power source: 220V AC(+10%,-15%)50Hz±2%

2. Work environment: -30°C—70°C

3. Work environment of sensors: -1°C—55°C

4. Work environment of digital terminal: 1°C—40°C

5. Relative humidity:20%--90% RH

6.Weight accuracy: Base on OIML R76

Features of digital truck scales

1. Numeral transformation technology and compensation
The Inner part of the weighing load cell contains module conversion device and CPU processing unit.
Auto-compensation with digital technology to the parameter of load cell such as non-linearity, temperature, etc.
Free of calibrating for the scale if the load cells are replaced.
2. With the calibrating and digital technology, bias-load (four corners) calibration of the truck scale can be completed only once.
3. Digital communications technology
The central line structure can be used by several weighing load-cells (up to 32) in the same system.
RS485 interface is used and long-distance signal transmission is possible, with the transmission distance not less than 1000m.
Output signal at 3~4V strengthens the capability of anti-interference and lightening protection of the system.
4. Intelligent technology
The parameter of the load cell can be changed according to the orders.
Different wave-filtering ways can be adopted according to different situations.
5. Module, standard and series scale body, multiunit assembly
6. Digital load cell of full-sealing column and laser-welded stainless steel, with accuracy of C3, strong water-proof and anti-corrosive function

Pinglei is located in Shijiazhuang, Hebei Province, build in 2005. My factory is the largest weighbridge manufacture in North China. We have almost 100 employees in R&D, management, sales and production. We produce truck scales by our own design. Our annual sales reached 10 millions US dollars in 2008,and 80% of sales is from the oversea market.

Pinglei has got a certification of ISO 9001:2015.We concentrate all of our resources to provide the best prices to our customers with top-grade products. The design, manufacturing, inspection and test of our products meet customers demands and all related standards.

We have a strong R&D team who has rich experience in developing various scales, and constantly present new types of products according to the demands of oversea markets. We have various production and testing equipments which are necessary for producing products with high quality. Besides, we have many operators with rich experience, so each piece of our products could get the foreign customers hearty praise.

If you select Pinglei,it is just that you have chosen one advanced and reliable representative.

To choose Pinglei who is powerful and with abundant experience as your supplier, you will save more money and create more value.
