Truck scale width

3m,3.2m.3.4m,3.5m

Truck scale length

6m,7m,8m,9m,10m,12m,14m,16m,18m,20m,21m,22m,23m,24m

Truck scale Accuracy class

OIML(III)

Truck scale Capacity range

10-150(Ton)

Safe overload

150%

Truck scale Material

Q235 steel

Thickness of plate

10mm or 12mm

Truck scale Structure

U shape bridge construction stucture

Structure Thhickness

6mm

Truck scale Painting

Anti rust and anti corrosion painting

Truck scale Work temperature

Indicator:-10°C to +40°C Scale platform: -30°C to +65°C

power supply

220V 50HZ to 230V 60HZ or 110V 60HZ

Packing detail

Carton packing

Standard accessory part include:

Weighing indicator

Electronic type or digital type

Load cell/sensor

Electronic type or digital type

Printer

Panasonic Brand/Epson Brand optional

Junction boxes

Waterproof type wire junction boxes

Connect cable

20m or 30m(depends on the distance from scale house to scale)

Screw

Bolts-screws,limit screw,loading cell screw,cover plate screw

Installation tools

Inner six angle spanner,Uncrock spanners,Screwdriver.

Optional accessory part include:

Scoreboard

Convenience for seeing weighing result in the long distance.

Weighing management software

Install software in PC and operate the truck ID,tare,net,gross,accumulation etc intelligence automatic system.

PC

Brand desktop computer

Model

Table size scales Desk

Max(t)

Indexingee(Kg)

SCS-1

1×1.5

1.5×2

1

0.2

SCS-5

2.0×3

2.0×4

1.5×2

5

0.5

SCS-10

3.0×7

2.5×6

3.0×6

10

1

SCS-20

3.0×7

2.5×6

3.0×6

20

2

SCS-40

3.0×14

3.0×12

3.0×10

40

5

SCS-60

3.2×14

3.0×16

3.0×12

60

5

SCS-80

3.2×18

3.2×18

3.0×16

80

5

SCS-100

3.4×18

3.2×18

3.2×16

100

5

SCS-120

3.4×18

3.2×18

3.4×21

120

10

SCS-150

3.4×18

3.4×21

3.5×21

150

10

SCS-200

3.4× 18

3.4×21

3.5×21

200

20
