    Modular Truck Weighbridge IP68 Sensor Protection Long Term Stability

    Ask Lasest Price
    Brand Name : Pinglei
    Model Number : SCS
    Certification : ISO9001
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 100 Sets Per Week
    Delivery Time : 10 Days
    • Product Details
    • Company Profile

    Modular Truck Weighbridge IP68 Sensor Protection Long Term Stability

    Modular Truck Weighbridge IP68 Sensor Protection Long Term Stability


    1. Main Functions:


    a. widely used in the field like port, warehousing, factory, freight yard, etc. good performance, long term stability, reliability

    b. improve the efficiency of industrial/mining enterprises' entry and exit material trade settlement

    c.be deeply applied in the supervision of manufacturing process and enterprises’ general data system management

    d. meets the management requirement of modern weighing


    2. System features


    a. reduce the human cheating

    b. improve the working efficiency

    c. provide scientific basis for decision

    d. interface easy to operate

    e. high modularity

    f. easy to maintain

    g. avoid remote cheating


    3. Main Components


    Part 1: platform

    Part 2: load cell

    Part 3: indicator


    4. Equipment list


    descriptionnecessary or optionaldescriptionnecessary or optional
    full steel platformprinteroptional
    weighing sensorweighing management computeroptional
    weighing indicatorbig display screenoptional
    indicator signal wireweighing management softwareoptional
    embedded fittingsAC stability power supplyoptional
    current surge protector

    Item

    Capacity(MT)

    Platform Size(m)

    Module/Section

    Load Cell

    Graduation

    SCS-20t

    20

    2.3×5m

    1/1

    4

    5 kg

    2.3×8m

    2/2

    6

    SCS-30t

    30

    3×5.8m

    1/2

    4

    10 kg

    3×9m

    2/4

    6

    3×11.4m

    2/4

    6

    SCS-50/

    60t

    50/60

    3×9m

    2/4

    6

    10 kg

    3×11.4m

    2/4

    6

    3×16m

    3/6

    8

    SCS-80t

    80

    3×11.4m

    2/4

    6

    20 kg

    3×16m

    3/6

    8

    3.2×16m

    3/6

    8

    SCS-100t

    100

    3×14m

    2/4

    6

    50 kg

    3×16m

    3/6

    8

    3.4×18m

    3/6

    8

    SCS-120t

    120

    3×16m

    3/6

    8

    50 kg

    3.2×18m

    3/6

    8

    3.4×21m

    4/8

    10

    SCS-150t

    150

    3×16m

    3/6

    8

    50 kg

    3.2×18m

    3/6

    8

    3.4×21m

    4/8

    10
